Multi-Injector Non-Surgical Liposuction with the Ozone Therapy Device MEDOZONS® Beauty
How to Buy
Leave your details in the form below. We'll contact you and help to solve your questions.
The information which you give in completing this form will be forwarded to the designated party for its use and will not be provided by us to any other parties.
1. Purpose
The device MEDOZONS ® Beauty can be used in ozone therapy rooms of medical institutions of various profiles, but is particularly popular in medical centers that implement various anti-cellulite programs.
The device allows you to perform all procedures of local and systemic ozone therapy (more than 30), but its highlight is considered to be the procedure of multi-injector low-flow ozone administration in local lipodystrophy.
2. Design Features
When creating the device MEDOZONS ® Beauty, we have considered 15 years of successful experience in the operation of ozone therapy devices MEDOZONS ® BM-02 and MEDOZONS ® BM-03. In addition to the capabilities of these models, we have taught the MEDOZONS ® Beauty to smoothly change the ozone delivery rate to subcutaneous fat. In this way, one can choose the intensity of the procedure individually and increase the efficiency and comfort during the procedure.
3. Technical Data
4. The device provides
Touch screen
with an intuitively understandable interface in Russian and English allowing the operator to fully control the treatment process.
Built-in
ozone concentration measurer.
Convenient work
in TASK mode – treatment procedures are combined into groups with preset parameters.
Treatment procedures
are timed; a convenient mnemonic diagram and text hints are displayed on the screen.
For the treatment procedure "Multi-Injector"
individual selection and control of the rate of subcutaneous ozone administration are provided.
5. Like all devices of Medozons series
Like all devices of Medozons series, the MEDOZONS ® Beauty is reliable, safe, easy-to-use, provides effective, safe and dose-dependent treatment, and comes complete with company accessories.
The Technique of Multi-Injector Non-Surgical Liposuction
1. Procedure performance
1.1.
Carry out a warming massage of the problem area, treat with 70% alcohol.
1.2.
Connect the "comb" with needles to the outlet nozzle of the MEDOZONS ® Beauty (Pic. 1, 3, 4). On the screen, select the "Multi-Injector" procedure. Set the ozone concentration and the "Intensity" parameter (for the first procedure, set the value to 50). Press "START". When the set ozone concentration is reached, open the faucet of the outlet nozzle.
1.3.
Remove the protective caps from sterile needles, insert the needles subcutaneously at an angle of 30 degrees around the perimeter of the problem area at a distance of 7-10 cm from each other (Pic. 2). In the first 2-3 minutes of the procedure, the patient may feel a slight bursting of tissue at the needle injection site. If necessary, select the value of the "Intensity" parameter.
Carry out a warming massage of the problem area, treat with 70% alcohol.
1.2.
Connect the "comb" with needles to the outlet nozzle of the MEDOZONS ® Beauty (Pic. 1, 3, 4). On the screen, select the "Multi-Injector" procedure. Set the ozone concentration and the "Intensity" parameter (for the first procedure, set the value to 50). Press "START". When the set ozone concentration is reached, open the faucet of the outlet nozzle.
1.3.
Remove the protective caps from sterile needles, insert the needles subcutaneously at an angle of 30 degrees around the perimeter of the problem area at a distance of 7-10 cm from each other (Pic. 2). In the first 2-3 minutes of the procedure, the patient may feel a slight bursting of tissue at the needle injection site. If necessary, select the value of the "Intensity" parameter.
Pic. 1 MEDOZONS ® Beauty with the connected "comb"
Pic. 2 Introduction of ozone to the "breeches" zone
Pic. 3 "Comb", Order No. 103/01
Pic. 4 Needles G30 0.3x13, Order No. 101/02
1.4.
After 3-5 minutes, at the injection site there is a slight hyperemia and tuberosity of the skin, subsequently it intensifies until the merger of separate areas.
1.5.
The medical staff needs to constantly monitor the progress of the procedure and, when the areas of hyperemia and (or) tuberosity are merged, move the needles to areas not covered by hyperemia.
1.6.
The duration of the procedure is 10-15 minutes, during this time 100-150 ml of ozone-oxygen gas mixture is introduced (the approximate coverage area is 4-7% of the body surface). To end the procedure, press the "STOP" button, close the faucet of the outlet nozzle. For uniform distribution of ozone in the subcutaneous fat, massage the problem area (manually or using an apparatus).
1.7.
In one procedure, it is possible to introduce an ozone-oxygen gas mixture into several problem areas, for which, during the procedure, needles are moved (for example, from the right thigh to the left), while the total time of the procedure and the volume of injected ozone-oxygen gas mixture remain unchanged.
1.8.
After the procedure, crepitus (crunching) can be observed, both in the places of direct injection of the ozone-oxygen gas mixture, and in remote areas of the body, which is not a complication, but only a consequence of a successful procedure. Crepitus can last up to 2 days.
1.9.
The advantages of this method compared with the introduction of ozone by the single-syringe method:
After 3-5 minutes, at the injection site there is a slight hyperemia and tuberosity of the skin, subsequently it intensifies until the merger of separate areas.
1.5.
The medical staff needs to constantly monitor the progress of the procedure and, when the areas of hyperemia and (or) tuberosity are merged, move the needles to areas not covered by hyperemia.
1.6.
The duration of the procedure is 10-15 minutes, during this time 100-150 ml of ozone-oxygen gas mixture is introduced (the approximate coverage area is 4-7% of the body surface). To end the procedure, press the "STOP" button, close the faucet of the outlet nozzle. For uniform distribution of ozone in the subcutaneous fat, massage the problem area (manually or using an apparatus).
1.7.
In one procedure, it is possible to introduce an ozone-oxygen gas mixture into several problem areas, for which, during the procedure, needles are moved (for example, from the right thigh to the left), while the total time of the procedure and the volume of injected ozone-oxygen gas mixture remain unchanged.
1.8.
After the procedure, crepitus (crunching) can be observed, both in the places of direct injection of the ozone-oxygen gas mixture, and in remote areas of the body, which is not a complication, but only a consequence of a successful procedure. Crepitus can last up to 2 days.
1.9.
The advantages of this method compared with the introduction of ozone by the single-syringe method:
- increase in efficiency by 15-30%;
- reduction of injuries of the skin due to a decrease in the number of injections by 6-10 times;
- more uniform distribution of ozone over the region of injections;
- absence of bruises and hematomas at the injection sites.
2. Contraindications, restrictions
2.1.
Contraindications for the procedure:
bleeding disorder;
thyroid disease;
acute inflammatory diseases.
2.2.
To avoid adverse effects during ozone therapy procedures, the following principles must be strictly followed:
with the local introduction of an ozone-oxygen gas mixture, the use of other medicines in the same place should be avoided;
at the beginning of the course of treatment, it is necessary to carry out a trial ozone therapy procedure, during which it is necessary to carefully monitor the patient.
2.3.
Ozone therapy is combined with the use of any pharmaceutical preparations (except anticoagulants) and with any physiotherapy, but it is necessary to strictly follow the separate principle of the procedures.
The main causes of the few complications are the incorrect technique for administering an ozone-oxygen gas mixture and the wrong dosage.
2.4.
Ozone therapy procedures can be carried out by both a doctor and nursing staff, but the first procedure should be performed in the presence of a doctor. The procedure should be stopped immediately at the slightest deterioration in the patient's condition.
2.5.
During the procedure, it is necessary to use only standard equipment and accessories.
2.6.
It is recommended to equip the treatment room with forced-air and exhaust ventilation, air conditioning or a window leaf fan to prevent the inhalation effect of ozone on the medical staff.
Contraindications for the procedure:
bleeding disorder;
thyroid disease;
acute inflammatory diseases.
2.2.
To avoid adverse effects during ozone therapy procedures, the following principles must be strictly followed:
with the local introduction of an ozone-oxygen gas mixture, the use of other medicines in the same place should be avoided;
at the beginning of the course of treatment, it is necessary to carry out a trial ozone therapy procedure, during which it is necessary to carefully monitor the patient.
2.3.
Ozone therapy is combined with the use of any pharmaceutical preparations (except anticoagulants) and with any physiotherapy, but it is necessary to strictly follow the separate principle of the procedures.
The main causes of the few complications are the incorrect technique for administering an ozone-oxygen gas mixture and the wrong dosage.
2.4.
Ozone therapy procedures can be carried out by both a doctor and nursing staff, but the first procedure should be performed in the presence of a doctor. The procedure should be stopped immediately at the slightest deterioration in the patient's condition.
2.5.
During the procedure, it is necessary to use only standard equipment and accessories.
2.6.
It is recommended to equip the treatment room with forced-air and exhaust ventilation, air conditioning or a window leaf fan to prevent the inhalation effect of ozone on the medical staff.
Other Generators
Send Web Form to Us
The information which you give in completing this form will be forwarded to the designated party for its use and will not be provided by us to any other parties.
FAQ
You've brought up the problem of toxic impurities possibly containing in the delivered ozone/oxygen mixture. Is it really so important?
Every doctor using ozone therapy must be sure of its safety, thus there must be no doubt about the purity of delivered ozone/oxygen gas mixtures for medical use (they should be contaminant-free).
We consider this problem as very important. It is a fact that after approx. 100 hours of continuous operation owing to the electrochemical erosion of the ozonization chamber walls and electrodes some of available ozone generators deliver an ozone/oxygen gas mixture contaminated by impurities (calcium, aluminium, silicon, magnesium, copper etc) in concentrations considered as dangerous for the health that however can become evident even some months or years after the treatment. This claim is valid through the investigation of the upper layer taken from the ozonization chamber wall. There are only two possible reasons for the products which were found out on the wall:
Parenteral methods of ozone therapy are safe only if the ozone generator delivers pure contaminant-free medical ozone. Each medical ozone generator should be equipped with a filter for extra purification of oxygen used; purity of delivered ozone/oxygen gas mixtures should be guaranteed by the manufacturer through available test protocols, the same is about accuracy in maintaining the chosen ozone concentration (not worse than 10%) and great operation resource (durability) of ozonization chamber (without any decrease in the ozone production and without any change in ozone concentration accuracy) for at least 2000 hours of continuous operation.
We consider this problem as very important. It is a fact that after approx. 100 hours of continuous operation owing to the electrochemical erosion of the ozonization chamber walls and electrodes some of available ozone generators deliver an ozone/oxygen gas mixture contaminated by impurities (calcium, aluminium, silicon, magnesium, copper etc) in concentrations considered as dangerous for the health that however can become evident even some months or years after the treatment. This claim is valid through the investigation of the upper layer taken from the ozonization chamber wall. There are only two possible reasons for the products which were found out on the wall:
- Destruction of the electrodes (the discovered products are equivalent to the materials of electrodes);
- Fine contaminants possibly containing in oxygen which during the ozonolysis can be converted into toxic products.
Parenteral methods of ozone therapy are safe only if the ozone generator delivers pure contaminant-free medical ozone. Each medical ozone generator should be equipped with a filter for extra purification of oxygen used; purity of delivered ozone/oxygen gas mixtures should be guaranteed by the manufacturer through available test protocols, the same is about accuracy in maintaining the chosen ozone concentration (not worse than 10%) and great operation resource (durability) of ozonization chamber (without any decrease in the ozone production and without any change in ozone concentration accuracy) for at least 2000 hours of continuous operation.
What do you think about oxygen concentrators used as Oxygen Supply Systems for medical ozone generators?
There is no definite opinion at this point. Oxygen produced by these devices very seldom reaches the purity of 95% and higher, and we don not know whether the remaining 5% of content would not be dangerous due to electric synthesis in the ozonization chamber or interaction with ozone.
As you know, medical ozone generators require the use of medical oxygen referred to oxygen gas with guaranteed purity of 99,9% and higher. Anyways, we do not mind the use of oxygen concentrators for external i.e. local methods of ozone therapy.
As you know, medical ozone generators require the use of medical oxygen referred to oxygen gas with guaranteed purity of 99,9% and higher. Anyways, we do not mind the use of oxygen concentrators for external i.e. local methods of ozone therapy.
Would you please explain a necessity for a built-in oxygen filter in medical ozone generators?
Our previous experience has shown that oxygen used can contain micro-quantities of technical oils, thus each ozone generator intended for medical use should be equipped with a filter for extra purification of oxygen that inhibits the introduction of technical oils possibly containing in oxygen into the ozonization chamber. During the ozonolysis technical oils can be converted into dangerous toxic products (fatty acids, ketones, aldehydes etc).
Within a long operation time of ozone generator great volumes of oxygen are conveyed through the ozonization chamber (within 100 hours of operation in case of saline ozonization at a flow-rate of 1 L/min approx. 6000 L of oxygen are conveyed through the ozonization chamber), the ozonization chamber gradually becomes covered with an oily layer, and the doctor cannot be sure of the quality of gas mixtures delivered, thus extra purification of oxygen through a filter at the inlet of ozone generator is a reasonable step.
Within a long operation time of ozone generator great volumes of oxygen are conveyed through the ozonization chamber (within 100 hours of operation in case of saline ozonization at a flow-rate of 1 L/min approx. 6000 L of oxygen are conveyed through the ozonization chamber), the ozonization chamber gradually becomes covered with an oily layer, and the doctor cannot be sure of the quality of gas mixtures delivered, thus extra purification of oxygen through a filter at the inlet of ozone generator is a reasonable step.
Would you please explain the parameter "Range of selecting the dose of ozone"?
It is puzzling to us that some manufacturers of medical ozone generators use the parameter "Ozone production per 1 hour". This parameter was obviously taken from the ozone technology for water treatment, but in the medicine the ozone production should be adjustable at least per 1 min
How important is the accuracy of +/-5% … +/-10% in maintaining the chosen ozone concentration and the adjustable range 1 : 9950, as far as I know, recently these parameters have not been taken into consideration?
Before the New-Generation of medical ozone machines characterized by unique accuracy in maintaining the chosen ozone concentration and a uniquely wide range of ozone concentration adjustment, the doctors using ozone therapy were conditioned by the "traditional" types of ozone generator with very low accuracy in maintaining the chosen ozone concentration (worse than 40-50% as a rule) and a narrow adjustable range (1 : 15 - from 1 mg/l to 15 mg/l). The ozone concentration accuracy of +/-5% …+/-10% ensures a reasonable, predictable and dose-related therapy.
The high accuracy in maintaining the chosen ozone concentration allows using ozone like any other generally accepted medicine. That might have been one of the obstacles for wide spreading of ozone therapy. Nevertheless, all advantages of the Medozons machine do not influence its price, but this is a fact that there are many medical ozone generators on the market being much more expensive, but inferior in technical properties as compared with our machines.
The high accuracy in maintaining the chosen ozone concentration allows using ozone like any other generally accepted medicine. That might have been one of the obstacles for wide spreading of ozone therapy. Nevertheless, all advantages of the Medozons machine do not influence its price, but this is a fact that there are many medical ozone generators on the market being much more expensive, but inferior in technical properties as compared with our machines.
The parameters "Range of ozone concentration adjustment 1:9950" and "Range of selecting the dose of ozone 0,25 … 10000" are not clear to us.
Would you please explain it?
Would you please explain it?
We can explain it with the Medozons-BM:
So, medical ozone generators of Medozons series are able to produce guaranteed pure medical ozone and dose it exactly, with regards to technical and medical features they are the best ones within Russia and have no analogies worldwide! We are sure that the above parameters today considered as unique tomorrow will be the new standards of ozone therapy.
- Range of delivered ozone concentrations (50…10 000) mcg/L. This parameter means that the machine is able to maintain the chosen ozone concentration within the available range with accuracy not worse than +/- 10%: 107 mcg/L or 5671 mcg/L.
- The parameter "Range of ozone concentration adjustment (1 : 9950)" means that the machine is able to provide 9950 values/gradations of ozone concentration with accuracy +/-10% that characterizes the depth of adjustment.
- The range of selecting the dose of ozone characterizes a wide range of ozone dosage adjustment from 0,25 mcg/L to 10000 mcg/L with accuracy +/-5%, at an ozone/oxygen flow-rate of 0,25 L/min adjustable by step 0,25 mcg; 0,5 L/min - 0,5 mcg; 1 L/min - 1 mcg.
So, medical ozone generators of Medozons series are able to produce guaranteed pure medical ozone and dose it exactly, with regards to technical and medical features they are the best ones within Russia and have no analogies worldwide! We are sure that the above parameters today considered as unique tomorrow will be the new standards of ozone therapy.
Would you please explain a necessity for an automated system of ozone-oxygen flow-rate adjustment, what about doing it manually by means of oxygen flow regulator? The use of fixed flow-rates (0,25; 0,5; 1,0 L/min) may limit the range of ozone applications.
Manually setting of oxygen flow-rate by means of regulator may induce a considerable decrease in ozone dosage accuracy (the dose of ozone = CO3 x O2/O3 flow-rate x treatment time) due to possible oxygen pressure fluctuations (in oxygen tank or any other oxygen supply system) or any change in gas tract resistance.
In medical ozone generators of Medozons series oxygen flow-rate delivered to the ozonization chamber is automatically stabilized at the given level regardless of influence from outside, the automated stabilization system of oxygen flow-rate is reliable even in case of considerable pressure fluctuations that ensures a dose-related therapy. The automatic gas supply system is tested by the manufacturer for accuracy in maintaining the chosen oxygen flow-rate. We are convinced that the fixed O2/O3 flow-rates do not limit, but widen the range of ozone applications, most of doctors perform ozone therapy at a flow-rate of 1 L/min, but using a flow-rate of 0,5 or 0,25 L/min it is possible to successfully perform intracavitary ozone therapy (in gynecology, urology etc).
In medical ozone generators of Medozons series oxygen flow-rate delivered to the ozonization chamber is automatically stabilized at the given level regardless of influence from outside, the automated stabilization system of oxygen flow-rate is reliable even in case of considerable pressure fluctuations that ensures a dose-related therapy. The automatic gas supply system is tested by the manufacturer for accuracy in maintaining the chosen oxygen flow-rate. We are convinced that the fixed O2/O3 flow-rates do not limit, but widen the range of ozone applications, most of doctors perform ozone therapy at a flow-rate of 1 L/min, but using a flow-rate of 0,5 or 0,25 L/min it is possible to successfully perform intracavitary ozone therapy (in gynecology, urology etc).
How would you explain the fact that your ozone generators are not equipped with a measuring device to determine the delivered ozone concentration? To my mind, this can discredit the method of ozone therapy. From my own experience I know that at the starting point any medical ozone generator has the actual accuracy of delivered ozone concentration +/-40…+/-80%.
In medical ozone generators of Medozons series like Medozons-BM and BM-02 you can see a different functional principle of the ozonization chamber that ensures a wide range of ozone concentration adjustment (from 50 to 10000 mcg/L) with high accuracy in automatically maintaining the chosen ozone concentration not worse than +/- 10%, in fact, the actual accuracy tested by the manufacturer is not worse than +/- 5%. The attested accuracy is valid for at least the same time as the specified durability of the ozonization chamber before the scheduled prophylactic service (2000 hours of continuous operation or about 5 years of usage). The latest device Medozons-System has a built-in measurer of ozone concentratrions.
